Beverly Voth, Claris Platform, Claris Pro, Claris Studio, Level: Intermediate

Claris Studio (part 3) – Spreadsheet: Details, please!

About the author: Beverly Voth has been in the Claris FileMaker community many years. In addition to FileMaker Pro and its integrated products, she is a Full Stack Web developer & SQL database administrator. The only recipient of the FileMaker Excellence Award for Outstanding Contribution to the FileMaker Web Publishing Community (DevCon 2003), she’s been advocating Claris FileMaker and web since they could work together.

This is part three of a series on the new Claris platform. We introduced the overview, Claris Studio, Tell Me More! on 29 September 2022, and Claris Studio (part 2) – Integration with Claris Pro on 12 October 2022. This article gets into more details on the different types of views in Claris Studio. Since the spreadsheet view will likely be a most common usage for many, this article will be devoted to it. The spreadsheet view in Claris Studio has plenty of goodies & features, and can be used to create Dashboard views (charts and summary text).

A new spreadsheet view – with default fields, table name, & view name

Claris Studio, Spreadsheet View

Of all the views available in Claris Studio, the spreadsheet is a very flexible table for data entry & editing, sorting & grouping. These web-based data grids (tables) are more robust than FileMaker/Claris Pro table view, better than web viewer data tables (easier at least!), but probably not as full-featured as Excel or Numbers spreadsheets. There are no “cell” formulas or references as in some spreadsheets, but there is a way to present a grid of rows & columns for data entry, viewing, and reporting. Web-based data grids may use methods that allow drag-and-drop re-arrangement of rows and/or columns, as you will find in Claris Studio’s spreadsheet.

There are several JavaScript & CSS techniques & frameworks or libraries used for tables on the web. Many of them have been integrated into FileMaker Pro (and now Claris Pro) though Web Viewers.

But they all look like coding down and dirty. That’s great if that’s what you want to do. Would you like something easier? Would you like to send this data to the other Claris Studio view types, including dashboards (charting)? And would you like to share the data collected with Claris Pro? Let’s get started with the finer points of spreadsheets in Claris Studio! Continue reading “Claris Studio (part 3) – Spreadsheet: Details, please!”

Beverly Voth, Claris Platform, Claris Pro, Claris Studio, Level: Intermediate

Claris Studio (part 2) – Integration with Claris Pro

About the author: Beverly Voth has been in the Claris FileMaker community many years. In addition to FileMaker Pro & its integrated products, she is a Full Stack Web developer & SQL database administrator. The only recipient of the FileMaker Excellence Award for Outstanding Contribution to the FileMaker Web Publishing Community (DevCon 2003), she’s been advocating Claris FileMaker and web since they could work together.

Welcome back to part two of our Claris Studio & Claris Pro exploration. This article will cover Claris Pro and how it integrates with Claris Studio. Since we started with Claris Studio, Tell Me More!, there was a major update to the features in Claris Studio. You were advised to be alert! Check What’s New for the latest Claris Studio updates. This article is about conversion of Claris FileMaker Pro database files to Claris Pro files and how Claris Pro works with Claris Studio tables (two way interaction!)

What is Claris Pro?

Claris Pro is an application toolbox full of features that allow you to create user interfaces for data collection, display, and reporting. It can be used to create everything from a collection of Grandma’s recipes to full mission-critical business applications. It’s a cool and R.A.D. (pun intended!) toolbox for use by those starting out to full-stack relational database developers. Claris Pro uses a graphical interface for most creation, but easily works with external data exchanges. Once created with Claris Pro, these apps can be used on iPhones, iPads, or viewed in web browsers, as well as on the desktop/laptop by one user or thousands of users. You can use Claris Pro with Windows and macOS. Continue reading “Claris Studio (part 2) – Integration with Claris Pro”

Beverly Voth, Claris Platform, Claris Studio

Claris Studio, Tell Me More!

About the author: Beverly Voth has been in the Claris FileMaker community many years. In addition to FileMaker Pro & its integrated products, she is a Full Stack Web developer & SQL database administrator. The only recipient of the FileMaker Excellence Award for Outstanding Contribution to the FileMaker Web Publishing Community (DevCon 2003), she’s been advocating Claris FileMaker and web since they could work together.

This is the first in a series of articles exploring portions of the new Claris Platform. Launched in September 2022, this is just the beginning of the journey! Curious souls that we are, many question arise, and these articles are meant to supplement what we’ve seen so far, and perhaps give some different perspectives, along with plenty of screen shots. Concentration in these articles will be on Claris Studio and its relationship with Claris Pro.

Disclaimer: This platform may have rapid changes and this article may not be current after it is published. Always check for the latest information & videos.

What is Claris Studio?

Claris Studio is a cloud-based (access through a web browser) editor and data browser. A Claris ID is used to login and teams can be invited to join (by Claris ID). Access to view or edit can be constrained by inviting team members to Hubs with shared Views. The editor can create: Forms, Spreadsheets (tables), List-Detail Views, Dashboards (with charts and summary data), and Kanban Views. Some basic Views are preset for you to use as examples when you first start. There are many tooltip hints and popover & other dialogs to assist you along the way.

Continue reading “Claris Studio, Tell Me More!”

JSON, Level: Advanced, Version: FM 19.5 or later

JSON Custom Functions for FM 19.5, part 2

Demo Files

Note: some of the CFs have been revised and/or renamed since part 1, so if you plan to use these CFs, make sure to download today’s “part 2” file.

Introduction

Welcome back to JSON Custom Functions for FM 19.5, round two. In part 1 we explored these CFs…

…and today we’ll be taking a look at the ones we didn’t cover last time. As before, a key ingredient in some of these CFs is JSON.GetValueType, which auto-determines the type of an element that is being added to an object or an array.

Today’s Custom Functions

Disclaimer: use at your own risk, these CFs may contain bugs, these CFs may not be performant when processing large amounts of data, always test carefully before deployment, etc., etc., etc.

JSON.FromTextArray ( array_2d ; colDelimiter ; rowDelimiter ; optionalKeyList )

Purpose: generates either a 2-dimensional JSON array or an array of JSON objects from a delimited 2-dimensional input array (for example, the response from a SQL query). The absence or presence of optionalKeyList determines whether you get back this…

[ [ value, value, value... ], [ value, value, value... ], etc ]

…or this…

[ { key:value, key:value, key:value... }, { key:value, key:value, key:value... }, etc ]

For example, assume the following result of a SQL query is sitting in a $$sql.array variable…

9035|New Receivable|1|010.003.001.001
9036|Review & Post Receivables|1|010.003.001.002
9037|Unpost Receivables|1|010.003.001.003
9038|New Direct Receipt|1|010.003.001.004
9039|Apply Receipts|1|010.003.001.005
9040|Review & Post Receipts|1|010.003.001.006
9041|Apply Credits & Prepayments|1|010.003.001.007
9042|Unpost Bank Deposits|1|010.003.001.008

What we get back from the custom function depends on the final argument.

Ex. 1 — the final argument is blank so the CF returns an array of arrays.

Ex. 2 — the final argument contains a list of key names so the CF returns an array of objects.

(If you’re curious about JSON.Format2D, that was discussed in part 1.)

JSON.MapJsonFromTextArray ( array_2d ; map ; colDelimiter ; rowDelimiter )

This one comes from Cristos Lianides-Chin, and is used with his kind permission. It came about after I showed him the preceding CF and he replied, “You know what would be a logical next step? To implement a map.”

Purpose: Given a 2d text array, such as would be returned from ExecuteSQL, maps each array row into the schema of a JSON object and returns a JSON array of objects.

Example — using the same $$sql.array variable as above, and a $$map variable populated like so…

…this statement…

JSONFormatElements (
    JSON.MapJsonFromTextArray ( $$sql.array ; $$map ; "|" ; ¶ )
)

…produces this.

JSON.DedupeArray ( array )

Purpose: removes duplicate entries from a JSON array.

Example — given this input…

…here is the corresponding output.

JSON.ObjectFromRecord ( tableOccurrenceName ; fieldToExclude )

Purpose: creates a correctly-typed JSON object for the specified record.

Sometimes you want to create an object representation of a given record. You don’t want to be bothered with specifying fields, you just want it to work with a minimum of thought and effort on your part.

Note 1: if you use this CF in a calculated field do not use Get ( LayoutTableName ) as the first argument… reason: when you look at the field across a relationship, you will get the json object for the parent, not the child.

Note 2: if you use this CF in a calculated field, to avoid a circular reference make sure to pass that field name in as fieldToExclude, otherwise pass in "" for the second argument.

IMPORTANT: unfortunately GetFieldName ( Self ) cannot be hard-coded into a custom function but we can pass it in as a parameter.

Ex. 1 — a calculated field in the customers table defined like so…

…will return something like this.

Ex. 2 — this similarly-defined calculated field in the sales table…

…returns this.

In the above example, since the CF doesn’t pick and choose, the result includes the output from two other “as_json” fields. If we wanted to, we could modify the definition of as_json_record like so…

…to get those other two out of there.

JSON.OptionalObjectFromFieldList ( objectName ; fieldList ; customNameList )

Purpose: creates a correctly typed JSON object based on field list, ignoring empty fields.

Ex. 1 — without custom names (assuming affiliation and birthPlace are empty).

Ex. 2 — as above, but with custom names.

Note: as per the above example, customNameList can be sparsely populated to allow a combination of custom and native field names.

JSON.CountElements ( json )

Purpose: returns count of non-null elements in a JSON object or array.

Note: Counts each entry, excluding nulls. If you want to count *all* entries (including nulls) use JSON.CountKeys instead

This CF came about when I needed to count non-null entries in a JSON object and some of those entries included embedded returns. The following examples reference this $$json variable which includes a two-line “address” entry.

Ex. 1 — the typical “count values” approach will count one value for “company” and two values for “address”.

Ex. 2 — the custom function disregards \r and \n so each element is only counted once.

JSON.CountKeys ( json )

Purpose: as above, but counts keys instead of elements.

Note: although rarely encountered, it is possible for object keys to contain “vertical white space” characters such as hard returns, line feeds, "\n", "\r", etc.

Assuming a variable, $$wonkyKeys, populated like so…

…resulting in a key list that looks like this:

Ex. 1 — the typical approach will count each key twice.

Ex. 2 — the custom function gets it right.

JSON.ListAllValues ( json )

Purpose: behaves like JSONListValues but returns empty rows for nulls.

Note: works with both objects and arrays.

Ex. 1 — FileMaker’s JSONListValues function swallows the nulls.

Ex. 2 — the CF renders nulls as empty rows, thereby preserving the position of subsequent items in the list.

JSON.KeyExists ( json ; keyOrIndexOrPath )

Purpose: returns a 1 if specified key is present, otherwise returns 0.

Ex. 1 — does key exist within an object?

Ex. 2 — does key exist within an array?

JSON.Deflate ( json )

Purpose: unformats formatted JSON, with no harm done if the JSON isn’t formatted to begin with.

Example: given this formatted array…

…the custom function returns this:

Note: you can achieve the same result by doing this (which, in fact, is what the CF does under the hood):

JSONGetElement ( $$small.array ; "" )

JSON.IsValid ( input )

Purpose: returns a 1 when input is valid JSON, otherwise returns 0.

Ex. 1 — input is JSON.

Ex. 2 — input isn’t JSON.

Interlude

The remaining custom functions are featured in today’s second demo file, JSON Insert and Update for FM 19.5.

Back in 2019 I did a pair of articles regarding certain limitations of JSONSetElement, which you can read here if you are so inclined.

In a nutshell, the “update” CF was created to allow a multi-dimensional auto-generated array to overwrite a non-empty (i.e., existing) array address. And the “insert” CF was created to allow one to insert an element into an array, shifting all downstream elements one position rightward to accommodate.

So why write new CFs for FM 19.5? Because the demo files and accompanying CFs worked fine when FM 18 was the current version, but when FM 19 was released something broke, and rather than fix old code, I decided to update the CFs to take advantage of JSONGetElementType, and combine both of them into a single demo file.

JSON.UpdateElement ( source ; address ; element )

Purpose: works like JSONSetElement but doesn’t balk when overwriting an existing element with an autogenerated array.

Ex. 1 — given this source array…

…we can push an auto-generated array into address [1] (which currently contains null) using JSONSetElement.

However, if we instead target [2] (which currently contains an object) with JSONSetElement, chaos ensues.

Ex. 2 — JSON.UpdateElement to the rescue.

JSON.InsertArrayElement ( source ; address ; element )

Purpose: inserts an element into an array, with any existing array elements sliding one position rightward to accommodate.

Ex. 1 — FileMaker enables us to overwrite an existing value via JSONSetElement…

…but does not provide us with a corresponding function to insert a value into an array so that existing elements shift one position rightward.

Ex. 2 — JSON.InsertArrayElement remedies this shortcoming.

JSON.GetArrayElementPosition ( source ; address )

This is a helper CF used by JSON.InsertArrayElement.

Purpose: translates a JSON array address into the corresponding FileMaker position value.

Note: this CF disregards JSON formatting (if any) and always returns the position you would get if the source were unformatted.

Ex. 1 — given this source json…

…we can derive the corresponding FileMaker position for address [1] like so…

…or, if we want to save a few keystrokes, since this is a single-dimension address, like so:

Ex. 2 — this time with a more complex source and address.

JSON.ValidAddressSegment ( source ; address )

This is a helper CF used by JSON.UpdateElement and JSON.InsertArrayElement.

Purpose: identifies the portion of a target address that already exists in the source JSON.

Example — given this source and address…

…the “valid” address segment (the portion that already exists) can be determined like so.

Conclusion

I use some of these CFs once in a while, and others on a daily basis. If you’ve made it this far chances are you’ll find uses for one or more of them in your own work, and if you find any bugs, or have suggestions for improvement, I’d appreciate it if you would let me know by posting a comment here.

JSON, Level: Advanced, Version: FM 19.5 or later

JSON Custom Functions for FM 19.5, part 1

9/13/2022: Demo file has been updated to fix a bug in JSON.MergeArrays.

Demo File

Introduction

Today we have some custom functions (CFs) that can help you accomplish various JSON-related tasks in FileMaker. Back in 2018 I had this to say about JSON custom functions…

My inclination is to really understand something before I use a custom function to simplify things, but that’s a matter of personal choice… and one which can vary depending on the situation.

And four years later I find myself using JSON custom functions on a daily basis, to save time and to boost productivity — for example, to merge two objects into a single object, or to deduplicate an array. Continue reading “JSON Custom Functions for FM 19.5, part 1”

Level: Intermediate

Sometimes Less Is More Reliable

Update: Make sure to read Tony White’s comment below. It contains important additional information re: the behavior described in this article.

Recently I noticed some code that had worked flawlessly for years was suddenly returning “?” instead of valid values. What it came down to was that I had renamed my file from “JSON Custom Functions” to “JSON Custom Functions for FM 19.5”

Well you know those functions like ValueListItems…

ValueListItems ( fileName ; valueListName )

…that have a fileName argument? The culprit turned out to be that I was using Get(FileName) for that argument, and I needed to instead use "".

All 21 of the design functions are vulnerable to this, ahem, behavior. From the online help —

  • If you specify a filename that contains a period, include the filename extension in the parameter. Otherwise, functions may interpret the period in the filename as the beginning of the filename extension, which can lead to unexpected results.
  • If you specify no filename (""), functions return results for the current file.

Source:  https://help.claris.com/en/pro-help/content/design-functions.html

Bottom line:  When using a design function and referencing the current file, use "" instead of Get(FileName). There’s no down side, and your code won’t break if you decide to add a period to the file name.

JSON, Level: Intermediate, Version: FM 19.5 or later

Thinking About JSON, part 4

This article is part of a series. See also…
•  Thinking About JSON, part 1
•  Thinking About JSON, part 2
•  Thinking About JSON, part 3

Demo Files

Make sure to download the correct version for your locale:

Introduction

Welcome back to the fourth installment in this ongoing series. It’s hard to believe it’s been four years since the last segment, but in the meantime some exciting developments have occurred at the intersection of FileMaker and JSON, including… Continue reading “Thinking About JSON, part 4”

Level: Intermediate

Button Bar Segment Fun, part 2

This is a quick follow up to Tuesday’s article, and to avoid unnecessary repetition I will assume the reader is familiar with that material.

Demo Files

There were some things in v3 I wasn’t completely happy about, and I realized this morning that they would be easy to fix, and that the act of fixing them would help demonstrate the power of using this approach in the first place. Continue reading “Button Bar Segment Fun, part 2”

JSON, Level: Advanced, Version: FM 18 or later

Button Bar Segment Fun

Demo Files

Today we’re going to look at some ways single-segment button bars (SSBBs) can help produce dynamic column headings for list views and/or reports, with a goal of concentrating logic into the segment calculation and reducing schema dependencies elsewhere. This is a work in progress, rather than a finished, battle-hardened methodology. The aim is to explore possibilities and stimulate discussion.

Note: the demo files are built on top of an “empty” virtual list table. The point is not to (once again) dive into virtual list or clickable/sortable column headings, but to provide a list view we can pretend contains valid entries, while we focus on what’s going on in the layout header part.

Disclaimer: these techniques are in the proof-of-concept stage. As with all techniques on this (and any other) site, use with a healthy dose of common sense and at your own risk.

Continue reading “Button Bar Segment Fun”

ExecuteSQL, Level: Advanced, SQL, Version: FM 18 or later

Exploring Wordlespace with SQL and While

Recently we’ve discussed optimizing SQL queries in FileMaker, and had some fun with various SQL experiments. Today we’re going to explore some ways FileMaker can use ExecuteSQL and the While function to perform letter frequency and text pattern analysis on candidate words for the popular Wordle game.

The list of words comes from https://github.com/tabatkins/wordle-list and purports to include the actual answer words, as well as all allowable guess words. I don’t know how valid this list of words actually is, or, assuming it is currently valid, whether it is carved in stone or will change at some point in the future.

Demo file: SQL-Multi-Table-Experimentation-Wordle.zip

Some Notes

  • Today’s file is functionally identical to the one from last time; if you already have it, there’s no need to download this one.
  • No attempt is made to differentiate between daily Wordle words that have already appeared vs. those that have yet to appear.
  • SQL is case-sensitive in the WHERE clause; all our examples today use lower case letters so we may safely ignore the issue for the duration of this article.
  • For a general-purpose introduction to SQL in FileMaker, see Beverly Voth’s Missing FM 12 ExecuteSQL Reference.

Continue reading “Exploring Wordlespace with SQL and While”
